XVS8000 Sony Multi Format Switcher Processor Replacement Parts
Manufacturer
Model Number
XVS8000
Description
Multi Format Switcher Processor
Parts List
| Category | Part Number | Description | Demand |
|---|---|---|---|
| Screw | 1-842-404-11 | Sony Ac Inlet (Screw) 3P Fasten | |
| Adhesive | 7-600-000-48 | Sony Adhesive Agent(sc608lvz2)180ml | |
| A-1771-682-A | Sony Assembly, 7Seg | ||
| Switch | A-1771-683-A | Sony Assembly, Pbs | |
| 1-481-515-11 | Sony Bead, Ferrite (1608) | ||
| Lever | X-2583-078-2 | Sony Board Lever Gf Assembly | |
| Bracket, Flange, Blade | 4-170-582-02 | Sony Bracket, Panel | |
| 1-118-168-11 | Sony Cap Ceramic 1Uf X5r (0603) | ||
| 1-118-033-11 | Sony Cap, Ceramic 0.047Mf X5r(0603) | ||
| 1-118-388-11 | Sony Cap, Ceramic 0.047Mf X7r 1005 | ||
| 1-118-035-11 | Sony Cap, Ceramic 0.1Mf X5r (1005) | ||
| 1-118-596-11 | Sony Cap, Ceramic 0.1Mf X5r 0603 | ||
| 1-118-391-11 | Sony Cap, Ceramic 0.1Mf X7r 1005 | Y | |
| 1-116-744-11 | Sony Cap, Ceramic 0.22Mf X5r 1005 | ||
| 1-116-741-11 | Sony Cap, Ceramic 0.47Mf X5r 1005 | ||
| 1-114-472-11 | Sony Cap, Ceramic 1000Pf X7r (2000) | ||
| 1-118-403-11 | Sony Cap, Ceramic 1000Pf X7r 1005 | Y | |
| 1-116-756-91 | Sony Cap, Ceramic 100Mf X5r (2012) | ||
| 1-116-704-11 | Sony Cap, Ceramic 100Mf X5r 3216 | ||
| 1-116-865-11 | Sony Cap, Ceramic 10Mf (3216) | ||
| 1-118-047-11 | Sony Cap, Ceramic 10Mf X5r (2012) | ||
| 1-118-039-11 | Sony Cap, Ceramic 1Mf X5r (1608) | ||
| 1-116-737-11 | Sony Cap, Ceramic 1Mf X5r 1005 | ||
| 1-118-412-11 | Sony Cap, Ceramic 220Pf X7r 1005 | ||
| 1-116-713-11 | Sony Cap, Ceramic 22Mf X5r 2012 | ||
| 1-116-711-11 | Sony Cap, Ceramic 22Mf X5r 3216 | ||
| 1-116-709-11 | Sony Cap, Ceramic 22Mf X5r 3225 | ||
| 1-118-397-11 | Sony Cap, Ceramic 3300Pf X7r 1005 | ||
| 1-116-707-11 | Sony Cap, Ceramic 47Mf X5r 3216 | ||
| 1-116-506-91 | Sony Cap, Ceramic 47Uf X5r (2012) | ||
| 1-114-415-21 | Sony Cap, Elect 100Mf (5X5.9) | ||
| 1-114-250-21 | Sony Cap, Elect 150Mf (8X6.9) | ||
| 1-100-421-21 | Sony Cap, Elect 220Mf (6.3X5.9) | ||
| 1-107-819-11 | Sony Cap,ceramic 22000Pf/16v(1005) | ||
| 1-118-269-11 | Sony Cap,ceramic4.7ufx5r(1106) | ||
| 1-535-877-22 | Sony Chip,checker (Test Point) | ||
| Coil | 1-457-872-11 | Sony Choke Coil 3.3Uh | |
| A-2107-153-A | Sony Cn Blank Assembly | ||
| Coil | 1-457-497-11 | Sony Coil, Choke (Smd) | |
| Coil | 1-457-852-11 | Sony Coil, Choke 1.2Uh | |
| Coil | 1-460-370-11 | Sony Coil, Choke 10Uh (4018) | |
| Filter | 1-813-308-11 | Sony Common Mode Filter (Smd) | |
| Triac, Diode or Resistor | 1-218-990-81 | Sony Conductor, Chip (1005) | Y |
| Connector | 1-817-194-21 | Sony Connector 13P | |
| Connector | 1-819-993-21 | Sony Connector, Coaxial(bnc Double) | |
| Connector | 1-750-890-11 | Sony Connector,d-sub(angle Type)25p | |
| 1-561-067-00 | Sony Contact,female | ||
| 4-586-453-01 | Sony Cover,switch | ||
| Cushion | 4-549-937-01 | Sony Cushion (Htc B) | Y |
| Cushion | 4-458-668-01 | Sony Cushion (Lcd) | |
| Cooking Plate | 4-586-400-01 | Sony Cushion, Front Psu | |
| 4-586-460-01 | Sony Cushion,handle Vibration Proof | ||
| 6-503-573-01 | Sony Di 1Ss400smt2r | ||
| 6-502-352-01 | Sony Di Sml-522mu8wt86pq | ||
| 6-502-197-01 | Sony Di Sml-d12m8wt86sm | ||
| 6-502-598-01 | Sony Di Sml-d12u8wt86 | ||
| 1-400-382-21 | Sony Emi Ferrite (Smd) (1608) | ||
| Switch | 4-183-472-01 | Sony Escutcheon | |
| Fan Motor | 1-855-435-11 | Sony Fan, Dc (120 Square) | Y |
| Fan Motor | 1-855-201-11 | Sony Fan, Dc (120 Square) | Y |
| Fan Motor | 1-787-908-12 | Sony Fan, Dc (80 Square) | Y |
| 1-416-976-11 | Sony Ferrite, Emi (Smd) | ||
| 1-481-836-21 | Sony Ferrite, Emi (Smd) (1005) | ||
| 1-400-462-21 | Sony Ferrite, Emi (Smd) (1005) | ||
| 1-414-864-11 | Sony Ferrite, Emi (Smd) (1608) | ||
| 1-469-324-21 | Sony Ferrite, Emi (Smd) (2012) | ||
| Filter | 4-744-391-01 | Sony Filter | |
| Filter | 1-234-939-21 | Sony Filter, Emi Removal (Smd) | |
| 4-468-138-21 | Sony Foam (7X2), Shield | ||
| 5-036-959-01 | Sony Foam (7X2), Shield | Y | |
| Leg, Foot, Caster | X-3605-751-1 | Sony Foot Assembly (Abs) | |
| A-2107-154-A | Sony Front Blank Assembly | ||
| Fuse, Thermal Fuse, Breaker | 1-576-329-11 | Sony Fuse Chip 10A/125v (6125) | |
| Fuse, Thermal Fuse, Breaker | 1-533-627-21 | Sony Fuse Chip 5A/125v (6125) | |
| Handle | 3-172-089-01 | Sony Handle | |
| IC | 1-971-158-11 | Sony Harness, Sub Cn3825-sw | |
| 1-971-162-11 | Sony Harness, Sub Inlet-breaker | ||
| IC | 1-971-161-11 | Sony Harness, Sub Inlet-nf | |
| IC | 1-971-160-11 | Sony Harness, Sub Nf-mb | |
| 4-586-402-01 | Sony Holder | ||
| Holder | 2-990-241-02 | Sony Holder (A), Plug | Y |
| IC | X-2592-777-1 | Sony Holder Assembly, Fan Pc Board | |
| Housing | 1-561-828-00 | Sony Housing, Plug 3P | |
| IC | 6-722-201-01 | Sony Ic 74Lcx125ft | |
| IC | 6-722-204-01 | Sony Ic 74Lcx14ft | |
| IC | 6-722-208-01 | Sony Ic 74Lcx245ft | |
| Filter | 6-722-211-01 | Sony Ic 74Lcx32ft | |
| Bracket, Flange, Blade | 6-722-214-01 | Sony Ic 74Lcx540ft | |
| IC | 6-722-068-01 | Sony Ic 74Lcx541ft | |
| 6-722-224-01 | Sony Ic 74Vhc04ft | ||
| Panel | 6-722-248-01 | Sony Ic 74Vhc273ft | |
| Bracket, Flange, Blade | 6-722-278-01 | Sony Ic 74Vhct125aft | |
| IC | 6-714-073-01 | Sony Ic 88E1118r-a0-nnc2c000 | |
| Panel | 6-722-706-01 | Sony Ic 88E6176-a1-tfj2c000 | |
| IC | 6-705-213-01 | Sony Ic Adm1032arm-reel | |
| Sensor, Thermistor, Thermostat | 6-714-192-01 | Sony Ic Adt75brmz-reel | |
| IC | 6-714-616-11 | Sony Ic Ds90lv110atmtx | |
| IC | 6-710-776-01 | Sony Ic Lmh1981mtx/nopb | |
| IC | 6-716-910-01 | Sony Ic Lmh1983sqe/nopb | |
| IC | 6-714-109-01 | Sony Ic Lmk03000cisq | |
| IC | 6-717-747-01 | Sony Ic Lmp7711mk | |
| IC | 6-700-649-01 | Sony Ic Lt1720cms8#tr | |
| IC | 6-708-301-01 | Sony Ic Ltc4300a-2cms8#tr | |
| IC | 6-721-239-01 | Sony Ic M24c02-rmn6tp | |
| Power Control | 6-705-514-01 | Sony Ic Max3222ipwr | |
| 6-723-269-01 | Sony Ic Max3491csd+t | ||
| IC | 8-759-687-14 | Sony Ic Max4451eka-tg069 | |
| IC | 6-700-661-01 | Sony Ic Max4615cud+tg068 | |
| IC | 8-759-437-39 | Sony Ic Mb3771pf-er | |
| IC | 8-759-338-95 | Sony Ic Njm2903v (Te2) | |
| IC | 8-759-681-48 | Sony Ic Njm317dl1 | |
| IC | 8-759-388-63 | Sony Ic Nju7064v (Te2) | |
| IC | 6-704-641-01 | Sony Ic R3112n111a-tr-fa | |
| IC | 6-708-324-01 | Sony Ic R3112n301a-tr-fa | |
| Power Control | 6-707-908-01 | Sony Ic Sn65lvds122pwr | |
| IC | 6-702-547-11 | Sony Ic Sn65lvds2dr | |
| Power Control | 6-712-872-01 | Sony Ic Sn65lvds31pwr | |
| IC | 6-715-585-01 | Sony Ic Tc74lcx16245(el,f) | |
| IC | 6-710-786-01 | Sony Ic Tc7sh125fu(t5rsoyf | |
| IC | 6-715-038-01 | Sony Ic Tc7sz05fu,rsonyj | |
| IC | 8-759-655-22 | Sony Ic Tc7wh34fk(te85r) | |
| 6-722-613-01 | Sony Ic Tc7wh34fk,rsnj(ct | ||
| Regulator | 6-714-608-01 | Sony Ic Tps51200drcr | |
| IC | 6-717-068-01 | Sony Ic Tps54226rgtr | |
| IC | 6-716-852-01 | Sony Ic Tps54425pwpr | |
| 1-469-549-21 | Sony Inductor, Chip 1.0Uh (Lb2016) | ||
| 1-469-555-21 | Sony Inductor, Chip 10Uh (Lb2016) | ||
| 1-414-843-11 | Sony Inductor, Chip 18Nh (1005) | ||
| 1-414-521-41 | Sony Inductor, Small Type 10.0Uh | ||
| Label | 4-545-123-01 | Sony Label (10A), Fuse | |
| Cooking Plate | 4-586-401-01 | Sony Light, Guide | |
| 1-576-124-11 | Sony Link Ic 1A (3225) | ||
| A-2092-914-A | Sony M.c.b, Ca-92(compl) | Y | |
| A-2082-232-A | Sony M.c.b, Cn-3824 | ||
| A-2117-750-A | Sony M.c.b, Ex-1132b Mount | ||
| A-2117-749-A | Sony M.c.b, Ex-1296 Mount | ||
| A-2084-268-A | Sony M.c.b, Xpt-38(compl) | Y | |
| Jack | 1-822-629-11 | Sony Modular Jack(low Profile Giga) | |
| Board | A-2226-192-A | Sony Mounted C. Board, Ca-92a Compl | Y |
| Board | A-2198-817-A | Sony Mounted C. Board, Fp-301 Mount | |
| Board | A-2199-165-A | Sony Mounted C. Board, Hn-442 Mount | |
| Board | A-2198-813-A | Sony Mounted C. Board,cn-4018 Mount | |
| Board | A-2198-814-A | Sony Mounted C. Board,cn-4019 Mount | |
| Board | A-2225-826-A | Sony Mounted C. Board,cn-4020 Compl | |
| Nut | 3-942-866-02 | Sony Nut (M3) (3X0.5), Nylon | |
| Nut | 3-703-347-12 | Sony Nut (M4), Press | |
| 1-813-493-11 | Sony Oscillator, Crystal | ||
| 1-813-488-11 | Sony Oscillator, Crystal | ||
| 1-795-831-12 | Sony Oscillator, Crystal | ||
| Packing , Boxes , Packaging | A-5007-641-A | Sony Packing Assembly(front Board)(rp) | |
| Packing , Boxes , Packaging | A-5007-642-A | Sony Packing Assembly(rear Board)(rp) | |
| Circuit Board | 1-857-571-12 | Sony Pc Board, Mount(cpu-dp Module) | |
| Connector | 1-774-730-21 | Sony Pin, Connector (Pc Board) 3P | |
| Connector | 1-764-250-11 | Sony Pin, Connector (Pc Board) 4P | |
| Connector | 1-770-160-21 | Sony Pin, Connector (Smt) 2P | |
| Connector | 1-770-627-21 | Sony Pin, Connector 10P | |
| Pedestal | 4-143-559-01 | Sony Pin, Push | |
| Connector | 1-573-290-21 | Sony Pin,connector (4P)(smd)(1.5mm) | |
| Connector | 1-580-838-11 | Sony Pin,connector (Pc Board) 4P | |
| Transformer | 1-697-310-11 | Sony Pulse Transformer | |
| 1-474-652-16 | Sony Regulator, Switching | Y | |
| Regulator | 1-474-652-15 | Sony Regulator, Switching | |
| Regulator | 1-474-652-14 | Sony Regulator, Switching | |
| Relay | 1-755-379-11 | Sony Relay | |
| 1-257-105-11 | Sony Res, Chip 0.0022 (3264) | ||
| Triac, Diode or Resistor | 1-208-889-11 | Sony Res, Chip 1.2K (1005) | |
| 1-220-874-11 | Sony Res, Chip 15 (1005) | ||
| 1-208-691-11 | Sony Res, Chip 2.2K (1005) | ||
| Triac, Diode or Resistor | 1-208-871-81 | Sony Res, Chip 220 (1005) | |
| 1-208-872-81 | Sony Res, Chip 240 (1005) | ||
| Triac, Diode or Resistor | 1-218-937-81 | Sony Res, Chip 47 (1005) | |
| 1-208-932-81 | Sony Res, Chip 75K (1005) | ||
| 1-250-519-11 | Sony Res, Metal Film Chip 10K(1005) | ||
| 1-250-479-11 | Sony Res, Metal Film Chip 220(1005) | ||
| Triac, Diode or Resistor | 1-234-381-21 | Sony Res, Network 100Kx4 (1005) | |
| Triac, Diode or Resistor | 1-234-378-21 | Sony Res, Network 10Kx4 (1005) | |
| Triac, Diode or Resistor | 1-234-375-21 | Sony Res, Network 1Kx4 (1005) | |
| Triac, Diode or Resistor | 1-234-370-11 | Sony Res, Network 22X4 (1005) | |
| Triac, Diode or Resistor | 1-242-963-21 | Sony Res, Network 33X4 (1005) | |
| Triac, Diode or Resistor | 1-234-374-11 | Sony Res, Network 470X4 (1005) | |
| 1-250-495-11 | Sony Res,metal Film Chip 1.0K(1005) | ||
| 1-250-501-11 | Sony Res,metal Film Chip 1.8K(1005) | ||
| 1-250-503-11 | Sony Res,metal Film Chip 2.2K(1005) | ||
| 1-250-505-11 | Sony Res,metal Film Chip 2.7K(1005) | ||
| 1-250-509-11 | Sony Res,metal Film Chip 3.9K(1005) | ||
| 1-250-513-11 | Sony Res,metal Film Chip 5.6K(1005) | ||
| 1-250-517-11 | Sony Res,metal Film Chip 8.2K(1005) | ||
| 4-812-134-11 | Sony Rivet (Pla) | ||
| 3-531-576-11 | Sony Rivet,nylon | ||
| Wire | 4-098-036-01 | Sony Saddle Wire (A) | |
| Screw | 2-102-434-01 | Sony Screw (M3 (Eco)), Step | |
| 7-682-549-09 | Sony Screw +B 3X10 | Y | |
| Screw | 3-733-690-01 | Sony Screw +B 4X6 (St) | |
| Screw | 2-655-586-01 | Sony Screw +B M2.6 Eg | |
| 7-682-562-04 | Sony Screw +B4x10 | ||
| 7-685-645-79 | Sony Screw +P Ta3x6 Ep-fe/cu,ni.cr) | ||
| Screw | 7-628-253-00 | Sony Screw +Ps 2X4 | |
| Screw | 7-682-647-09 | Sony Screw +Ps 3X6(ep-fe/zn/cm2) | Y |
| Screw | 7-682-950-09 | Sony Screw +Psw 3X12(ep-fe/znbk/cm2 | Y |
| Screw | 7-682-951-09 | Sony Screw +Psw 3X14(ep-fe/zn/cm2) | Y |
| Screw | 7-682-655-09 | Sony Screw +Psw 3X30 | |
| Screw | 7-682-947-01 | Sony Screw +Psw 3X6 | Y |
| Screw | 7-682-663-01 | Sony Screw +Psw 4X12 | |
| Screw | 7-682-961-09 | Sony Screw +Psw 4X8 | |
| Screw | 3-637-901-02 | Sony Screw M2.6x5 | |
| Screw | 3-725-295-21 | Sony Screw, (+) (B3) | |
| Screw | 3-703-249-02 | Sony Screw, S Tight, +Pttwh 3X6 | |
| 7-621-759-40 | Sony Screw,+psw 2.6X6(ep-fe/zn/cm2) | ||
| Screw | 3-703-249-22 | Sony Screw,s Tight,+pttwh(m 3X8)(st | |
| Screw | 4-884-982-03 | Sony Screw,step | |
| Screw | 2-236-956-02 | Sony Screw,step | |
| IC | 4-187-619-01 | Sony Sheet,radiation(25x25x2) | |
| IC | 4-187-620-01 | Sony Sheet,radiation(33x33x1.5) | |
| Filter | 1-482-155-11 | Sony Smd Emi Filter | |
| Spacer | 3-994-237-01 | Sony Spacer | |
| Spacer | 3-654-058-02 | Sony Spacer (Dia 3X3) | |
| Stopper | 7-626-320-61 | Sony Spring Pin 3X18 (Steel) | |
| Switch | 1-798-563-11 | Sony Switch, Power | |
| Switch | 1-692-271-31 | Sony Switch, Slide | |
| Switch | 1-798-138-21 | Sony Switch, Slide (Smd) | |
| Switch | 1-771-721-11 | Sony Switch, Tactile | Y |
| 1-811-201-11 | Sony Thermistor, Positive | ||
| Sensor, Thermistor, Thermostat | 1-802-063-21 | Sony Thermistor, Positive | |
| 6-552-910-01 | Sony Tr Dtc023jebtl | ||
| 6-552-895-01 | Sony Tr Lta014eebfs8tl | ||
| 6-552-897-01 | Sony Tr Lta023jebfs8tl | ||
| 6-552-904-01 | Sony Tr Ltc014eebfs8tl | ||
| 6-552-700-01 | Sony Tr Ssm3k15amfv,l3sf | ||
| Transistor | 8-729-928-19 | Sony Transistor 2Sa1774r | |
| Transistor | 6-550-545-01 | Sony Transistor 2Sc4617ftlq | |
| Transistor | 8-729-929-08 | Sony Transistor Dtc123je-tl | |
| 1-813-267-11 | Sony Vibrator, Crystal | ||
| 1-813-052-21 | Sony Vibrator, Crystal | ||
| Washer | 3-650-537-01 | Sony Washer | |
| Washer | 7-623-925-01 | Sony Washer,plastic (4X0.5) |
