UPD55 Sony Digital A5 Color Video Printer Replacement Parts
Manufacturer
Model Number
UPD55
Description
Digital A5 Color Video Printer
Parts List
| Category | Part Number | Description | Demand |
|---|---|---|---|
| Screw | 4-676-937-01 | Sony #Value! | |
| 7-621-255-65 | Sony +Bvtt 2X10 (S) | ||
| Spool | A-1551-703-A | Sony Assembly, Pressure Spool | |
| Cover,Cap | X-3608-942-2 | Sony Assy,top Cover | |
| Ring | 3-603-423-01 | Sony Ball Bearing,non-flanged | |
| Band | 3-655-653-01 | Sony Band (Taiton), Binding (Pla) | |
| 1-500-112-11 | Sony Bead, Ferrite | ||
| Ring | 3-854-416-01 | Sony Bearing(630) | |
| Ring | 3-854-445-01 | Sony Bearing(850) | |
| Bearing | 3-154-532-11 | Sony Bearing, Radial | |
| Belt, Pulley | 3-854-437-01 | Sony Belt,timming(100tn15-3.0t | |
| 3-854-523-01 | Sony Block,guide,tray | ||
| Tray, Support , Ice Maker Tray | 3-854-523-02 | Sony Block,guide,tray | |
| Bracket, Flange, Blade | 3-854-570-02 | Sony Bracket(sw) | |
| Bracket, Flange, Blade | 3-854-486-02 | Sony Bracket,limiter | |
| Knob, Dial, Button | 3-854-571-03 | Sony Button,power | |
| 3-854-571-01 | Sony Button,power | ||
| Knob, Dial, Button | 3-854-571-02 | Sony Button,power | |
| 1-504-920-11 | Sony Buzzer,piezoelectric | ||
| 9-910-999-31 | Sony C-cap,u 560P-25 J Ch | ||
| 1-162-911-91 | Sony C-cap,u 6P-50 D Ch Grm | ||
| Capacitor | 1-162-912-11 | Sony C-cap,u 7P-50 D Ch Grm | |
| 1-216-849-11 | Sony C-res,u 220K-1/16w J | ||
| Cables, PCB Cable | 1-831-101-11 | Sony Cable, Flexible Flat (14 Core) | Y |
| 1-017-757-11 | Sony Cable, Flexible Flat (14 Core) | Y | |
| Cables, PCB Cable | 1-831-098-11 | Sony Cable, Flexible Flat (18 Core) | |
| Cables, PCB Cable | 1-831-100-11 | Sony Cable, Flexible Flat (20 Core) | |
| Cables, PCB Cable | 1-831-099-11 | Sony Cable, Flexible Flat (20 Core) | |
| 1-114-579-11 | Sony Cap, Ceramic 220Pf U2j (3216) | ||
| Capacitor | 1-107-826-11 | Sony Cap, Chip Ceramic 0.1Mf B | |
| 1-100-352-91 | Sony Cap, Chip Ceramic 1Mf B (1608) | ||
| 1-164-217-91 | Sony Cap,ceramic 150Pf Ch 1608 | ||
| 1-100-567-81 | Sony Cap,chip Ceramic 0.01Mf B 1005 | ||
| 3-854-505-01 | Sony Cap,ejection,tray | ||
| 3-854-436-01 | Sony Capstan | ||
| A-1060-941-A | Sony Cassette Assembly, Ribbon | ||
| A-8279-998-G | Sony Cassette Assembly,ribbon | ||
| A-8279-998-F | Sony Cassette Assembly,ribbon | ||
| A-8279-998-E | Sony Cassette Assembly,ribbon | ||
| A-8279-998-C | Sony Cassette Assembly,ribbon | ||
| A-8279-998-B | Sony Cassette Assembly,ribbon | ||
| A-8279-998-A | Sony Cassette Assembly,ribbon | ||
| A-8279-998-H | Sony Cassette Assy,ribbon | ||
| Connector | 1-535-757-11 | Sony Chip, Checker (Connector) | |
| Clamp | 3-854-589-02 | Sony Cks Clamp | Y |
| Clamp | 4-237-065-01 | Sony Clamp (L35) | |
| Coil | 1-419-630-11 | Sony Coil, Choke 4.7Uh | |
| Coil | 1-400-284-21 | Sony Coil, Common Mode Choke | |
| Disc | 2-059-521-05 | Sony Compact Disc | |
| 2-059-521-04 | Sony Compact Disc | ||
| 2-059-521-03 | Sony Compact Disc | ||
| 2-059-521-02 | Sony Compact Disc | ||
| 2-059-521-01 | Sony Compact Disc | ||
| 1-216-864-91 | Sony Conductor, Chip (1608) | Y | |
| Connector | 1-779-334-11 | Sony Connector, Ffc/fpc (Lif) 20P | |
| Connector | 1-766-350-51 | Sony Connector, Ffc/fpc (Lif) 20P | |
| Connector | 1-779-331-61 | Sony Connector, Ffc/fpc 14P | |
| Connector | 1-779-331-51 | Sony Connector, Ffc/fpc 14P | |
| Connector | 1-779-333-61 | Sony Connector, Ffc/fpc 18P | |
| Connector | 1-779-333-11 | Sony Connector, Ffc/fpc 18P | |
| Connector | 1-779-334-61 | Sony Connector, Ffc/fpc 20P | |
| Connector | 1-766-350-61 | Sony Connector, Ffc/fpc 20P | |
| Connector | 1-784-388-51 | Sony Connector, Ffc/fpc 32P | |
| Connector | 1-784-388-21 | Sony Connector, Ffc/fpc 32P | |
| Connector | 1-816-950-11 | Sony Connector, Memory Stick | |
| Connector | 1-794-962-11 | Sony Connector, Square Type 5P | |
| Connector | 1-815-194-11 | Sony Connector, Usb (B) | |
| Connector | 1-794-848-21 | Sony Connector,board To Cable(4 Pin | |
| Power Cord | 1-824-211-41 | Sony Cord, Connection | Y |
| 1-543-982-12 | Sony Core, Ferrite | ||
| Cover,Cap | X-3608-881-1 | Sony Cover Assy,door | |
| Cover,Cap | 3-854-559-03 | Sony Cover,chassis | |
| 3-854-557-01 | Sony Cover,power Switch | ||
| Cover,Cap | 3-854-557-02 | Sony Cover,power Switch | |
| Cover,Cap | 3-854-511-01 | Sony Cover,sensor(r),ribbon | |
| Cover,Cap | 3-854-609-05 | Sony Cover,tray | |
| Damper | 3-022-410-01 | Sony Damper | |
| Damper | X-3608-880-1 | Sony Damper Assembly | |
| 6-502-361-01 | Sony Di Ma3s132egls0 | ||
| Door,Remote Control Door | X-3608-895-3 | Sony Door Assembly,ribbon | |
| 3-854-572-02 | Sony Door,ribbon | ||
| 3-854-572-01 | Sony Door,ribbon | ||
| Door,Remote Control Door | 3-854-572-04 | Sony Door,ribbon | |
| 3-854-588-01 | Sony Edging(ce) | ||
| 1-469-670-11 | Sony Ferrite, Emi (Smd) | ||
| 1-469-637-11 | Sony Ferrite, Emi (Smd) | ||
| 1-469-116-21 | Sony Ferrite, Emi (Smd) | ||
| 1-469-112-11 | Sony Ferrite, Emi (Smd) | ||
| 1-414-445-11 | Sony Ferrite, Emi (Smd) | ||
| 1-469-324-21 | Sony Ferrite, Emi (Smd) (2012) | ||
| Filter | 1-234-494-21 | Sony Filter, Emi Removal (Smd) | |
| Belt, Pulley | 3-279-508-01 | Sony Flange (Belt) | |
| Ring | 3-854-417-01 | Sony Flange,bearing | |
| Belt, Pulley | 3-854-461-01 | Sony Flange,idler Pulley | |
| 3-854-513-04 | Sony Flap,ejection,paper | ||
| 3-854-513-02 | Sony Flap,ejection,paper | ||
| 3-854-513-01 | Sony Flap,ejection,paper | ||
| 3-854-513-05 | Sony Flap,ejection,paper | Y | |
| X-3704-817-1 | Sony Flap,paper | Y | |
| Cables, PCB Cable | 1-963-025-11 | Sony Flexible Flat Cable(14pin) | |
| Cables, PCB Cable | 1-963-022-11 | Sony Flexible Flat Cable(18pin) | |
| Cables, PCB Cable | 1-963-024-11 | Sony Flexible Flat Cable(20pin) | |
| Cables, PCB Cable | 1-963-023-11 | Sony Flexible Flat Cable(20pin) | |
| Leg, Foot, Caster | 3-993-780-01 | Sony Foot | |
| X-3608-879-1 | Sony Fulcrum Assembly | ||
| Gasket , Seal | 3-869-221-12 | Sony Gasket(rear) | |
| Gasket , Seal | 3-869-221-11 | Sony Gasket(rear) | |
| Gasket , Seal | 3-869-221-02 | Sony Gasket(rear) | |
| Gasket , Seal | 3-869-221-01 | Sony Gasket(rear) | |
| Gear, Wheel | 3-854-422-01 | Sony Gear(l),cam | Y |
| Gear, Wheel | 3-854-423-01 | Sony Gear(r),cam | Y |
| Gear, Wheel | 3-854-473-01 | Sony Gear(r),idler | |
| Gear, Wheel | 3-854-424-01 | Sony Gear(s),ribbon Idler | |
| Gear, Wheel | 3-854-425-01 | Sony Gear(t),ribbon Idler | |
| Gear, Wheel | 3-854-438-01 | Sony Gear,belt,pickup | |
| 3-854-426-03 | Sony Gear,connect | ||
| 3-854-426-01 | Sony Gear,connect | ||
| Gear, Wheel | 3-854-426-02 | Sony Gear,connect | |
| Gear, Wheel | 3-854-574-01 | Sony Gear,damper | |
| Gear, Wheel | 3-854-439-01 | Sony Gear,pickup | |
| Gear, Wheel | 3-854-476-01 | Sony Gear,ribbon | |
| Gear, Wheel | 3-854-427-01 | Sony Gear,sensor | |
| Circuit Board | 3-869-220-01 | Sony Guard,pc Board | |
| Guide | 3-854-626-03 | Sony Guide(t),ribbon | |
| Guide | 3-854-626-02 | Sony Guide(t),ribbon | |
| 3-854-414-05 | Sony Guide,bottom Paper | ||
| Guide | 3-854-414-04 | Sony Guide,bottom Paper | |
| 3-854-414-02 | Sony Guide,bottom Paper | ||
| 3-854-414-01 | Sony Guide,bottom Paper | ||
| Guide | 3-854-414-03 | Sony Guide,bottom Paper | |
| Guide | 3-854-514-06 | Sony Guide,center,paper | |
| Guide | 3-854-514-05 | Sony Guide,center,paper | |
| Guide | 3-854-514-04 | Sony Guide,center,paper | |
| 3-854-514-02 | Sony Guide,center,paper | ||
| 3-854-514-01 | Sony Guide,center,paper | ||
| Guide | 3-854-514-07 | Sony Guide,center,paper | |
| Guide | 3-854-507-06 | Sony Guide,feed | |
| Guide | 3-854-507-05 | Sony Guide,feed | |
| 3-854-507-03 | Sony Guide,feed | ||
| 3-854-507-02 | Sony Guide,feed | ||
| 3-854-507-01 | Sony Guide,feed | ||
| Guide | 3-854-507-07 | Sony Guide,feed | |
| 3-854-561-01 | Sony Guide,paper(b) | ||
| Guide | 3-854-561-02 | Sony Guide,paper(b) | |
| Wire | 1-962-976-13 | Sony Harness Bottom | |
| Wire | 1-962-976-12 | Sony Harness Bottom | |
| Wire | 1-962-965-13 | Sony Harness Ma(d)-mec(p) | |
| Wire | 1-962-965-12 | Sony Harness Ma(d)-mec(p) | |
| Wire | 1-962-975-12 | Sony Harness Pos_mtr0 | |
| Wire | 1-962-979-13 | Sony Harness Pos_mtr1 | |
| Wire | 1-962-964-12 | Sony Harness Power-head | |
| Wire | 1-962-970-12 | Sony Harness Pp_ej | |
| Wire | 1-962-978-12 | Sony Harness Pp_f_led | |
| Wire | 1-962-973-13 | Sony Harness Pp_in_led | |
| Wire | 1-962-971-11 | Sony Harness Pp_in_tr | |
| Wire | 1-962-968-13 | Sony Harness Rbn_tr | |
| Wire | 1-962-963-13 | Sony Harness, Sub (Power-ma(d)) | |
| 1-478-833-11 | Sony Head, Thermal (Tph172r1) | ||
| 3-854-467-03 | Sony Heat Sink | ||
| Clamp | 3-701-822-00 | Sony Holder, Wire | |
| Holder | 3-854-592-03 | Sony Holder,mec | |
| 3-854-510-05 | Sony Holder,roller,press | ||
| Roller | 3-854-510-03 | Sony Holder,roller,press | |
| 3-854-510-01 | Sony Holder,roller,press | ||
| Roller | 3-854-510-04 | Sony Holder,roller,press | |
| IC | 8-759-639-17 | Sony Ic 74Lvt244mtcx | |
| IC | 6-700-394-01 | Sony Ic Ba25bc0fp-te2 | |
| IC | 6-706-712-01 | Sony Ic Bd45401g | |
| IC | 6-701-825-01 | Sony Ic Bd4731g-tr | |
| IC | 6-702-001-01 | Sony Ic Bd7600fv-e2 | |
| IC | 8-759-654-91 | Sony Ic Cxd9137r | |
| IC | 6-803-770-01 | Sony Ic Cxd9182ar | |
| IC | 6-706-007-01 | Sony Ic Hy57v561620ctp-hdr | |
| IC | 6-702-639-01 | Sony Ic Hy57v561620ht-h | |
| IC | 6-700-246-01 | Sony Ic Ics511m-er | |
| IC | 6-804-576-01 | Sony Ic Lc4128v75tn100c-kty100 | |
| 6-804-576-03 | Sony Ic Lc4128v75tn100c-kty101 | ||
| IC | 6-804-576-02 | Sony Ic Lc4128v75tn100c-kty101 | |
| Power Control | 8-759-669-48 | Sony Ic Lm324pwr-12 | |
| Power Control | 6-710-749-01 | Sony Ic Lm324pwrg4 | |
| IC | 8-759-669-46 | Sony Ic Lm358pwr-12 | |
| Power Control | 6-710-629-01 | Sony Ic Lm358pwrg4 | |
| IC | 6-702-688-01 | Sony Ic M24c64-wmn6t(b) | |
| IC | 6-717-889-01 | Sony Ic M24c64-wmn6t(c) | |
| IC | 8-759-441-98 | Sony Ic Max3232cse+tg068 | |
| IC | 6-804-599-01 | Sony Ic Mbm29dl323te90tn-55v10 | |
| 6-805-840-01 | Sony Ic S29jl032h70tfi310-d55v11 | ||
| IC | 6-805-840-02 | Sony Ic S29jl032h70tfi310-d55v11b | |
| IC | 6-706-505-01 | Sony Ic Sla7060m-lf2104 | |
| IC | 6-712-233-01 | Sony Ic Sla7075mpr-lf2155 | |
| IC | 6-713-520-01 | Sony Ic Sla7076mpr-lf2155 | |
| Power Control | 8-759-675-48 | Sony Ic Sn74lvc32apwr | |
| Power Control | 8-759-573-97 | Sony Ic Sn74lvc541apwr | |
| Power Control | 6-700-804-01 | Sony Ic Sn74lvc574apwr | |
| IC | 8-759-234-04 | Sony Ic Ta7267bp | |
| IC | 8-759-075-70 | Sony Ic Ta75s393f | |
| IC | 8-759-334-77 | Sony Ic Ta8428k | |
| IC | 8-759-490-41 | Sony Ic Tc74vhct541aft(el) | |
| IC | 8-759-490-42 | Sony Ic Tc74vhct574aft(el) | |
| IC | 8-759-271-86 | Sony Ic Tc7sh04fu | |
| IC | 6-706-484-01 | Sony Ic Tc7sh04fu(t5rsoyjf) | |
| IC | 8-759-196-97 | Sony Ic Tc7sh32fu (Te85r) | |
| IC | 6-706-489-01 | Sony Ic Tc7sh32fu(t5rsoyjf) | |
| IC | 8-759-564-49 | Sony Ic Tc7w53fu-te12r | |
| IC | 8-759-560-62 | Sony Ic Tc7wh32fu-te12r | |
| IC | 8-759-591-61 | Sony Ic Tc7whu04fu | |
| IC | 6-706-704-01 | Sony Ic Tlv3402idgkr | |
| IC | 6-702-628-01 | Sony Ic Upd720122f1-dn1-e2-a | |
| 6-708-054-11 | Sony Ic V54c3256164vdi7(tp) | ||
| IC | 6-705-879-01 | Sony Ic Xc62ep1602mr | |
| 1-412-975-31 | Sony Inductor (Small Type) 0.47Uh | ||
| 1-412-946-11 | Sony Inductor 3.9Uh (2520) | ||
| 1-469-555-21 | Sony Inductor, Chip 10Uh (Lb2016) | ||
| 1-412-946-21 | Sony Inductor, Chip 3.3Uh (Lb2016) | ||
| 1-469-092-11 | Sony Inductor, Micro (Chip Type) | ||
| 1-414-760-21 | Sony Inductor, Micro (Chip Type) | ||
| 1-412-983-31 | Sony Inductor, Small Type 2.2Uh | ||
| Inlet | 1-251-373-11 | Sony Inlet, Ac | Y |
| 3-204-192-04 | Sony Instruction Fps | ||
| 3-854-583-01 | Sony Key(d),sheet | ||
| 3-854-583-02 | Sony Key(d),sheet | ||
| Label | 3-179-847-01 | Sony Label(northern Europe),caution | |
| Label | 3-218-172-01 | Sony Label, Caution | |
| Label | 3-188-177-22 | Sony Label, Fcc/ic (Class A) | |
| Led | 8-719-047-66 | Sony Led Cl-190d-cd | |
| Led | 8-719-060-95 | Sony Led Cl-200ir-x-tsl-bc | |
| Diode | 8-719-045-75 | Sony Led Cl-200ir-x-tu | |
| Lever | 3-854-575-02 | Sony Lever(ribbon) | |
| Lever | 3-854-575-01 | Sony Lever(ribbon) | |
| A-5002-526-A | Sony Limiter (S) Assembly | ||
| A-1060-945-A | Sony Limitter (S) Assembly | ||
| A-1060-946-A | Sony Limitter (T) Assembly | ||
| A-8286-000-C | Sony Limitter(s)assembly | ||
| A-8286-000-A | Sony Limitter(s)assembly | ||
| A-8286-000-B | Sony Limitter(s)assy | ||
| A-8286-001-F | Sony Limitter(t)assembly | ||
| A-8286-001-B | Sony Limitter(t)assembly | ||
| A-8286-001-A | Sony Limitter(t)assembly | ||
| A-5002-527-A | Sony Limitter(t)assembly | ||
| A-8286-001-C | Sony Limitter(t)assy | ||
| A-8286-001-D | Sony Limitter(t)assy | ||
| Ribbon | 3-854-478-01 | Sony Lock,ribbon | |
| Lock | 3-854-474-01 | Sony Lock,supply | |
| Magnet | 3-736-779-21 | Sony Magnet | |
| A-1060-906-A | Sony Mechanical (Main) Assembly | ||
| A-1081-382-B | Sony Mechanical (Main) Assembly,(mount) | ||
| A-1159-464-B | Sony Mechanical (Main) G Assembly, Rp | ||
| A-1159-464-A | Sony Mechanical (Main) G Assembly, Rp | ||
| Motor,Ice Maker Motor | 1-787-185-11 | Sony Motor, Fan | |
| Motor,Ice Maker Motor | 1-787-185-21 | Sony Motor, Fan | |
| Motor,Ice Maker Motor | 1-787-184-11 | Sony Motor, Stepping | |
| A-1059-610-A | Sony Mounted C. Board, Ccm-53 | ||
| A-1066-142-A | Sony Mounted C. Board, Ccm-54 | ||
| Circuit Board | A-1059-612-A | Sony Mounted C. Board, Ex-970 | |
| Circuit Board | A-1059-664-A | Sony Mounted C. Board, Ky-566 | |
| Circuit Board | A-1059-608-A | Sony Mounted C. Board, Mec-24 | |
| Circuit Board | A-1059-624-A | Sony Mounted C. Board, Se-747 | |
| Circuit Board | A-1059-642-A | Sony Mounted C. Board, Se-748 | |
| Circuit Board | A-1059-644-A | Sony Mounted C. Board, Se-749 | |
| Circuit Board | A-1059-646-A | Sony Mounted C. Board, Se-750 | |
| Circuit Board | A-1059-648-A | Sony Mounted C. Board, Se-751 | |
| Circuit Board | A-1059-650-A | Sony Mounted C. Board, Se-752 | |
| Circuit Board | A-1059-656-A | Sony Mounted C. Board, Se-755 | |
| Circuit Board | A-1059-658-A | Sony Mounted C. Board, Se-756 | |
| Circuit Board | A-1059-660-A | Sony Mounted C. Board, Se-762 | |
| Circuit Board | A-1059-666-A | Sony Mounted C. Board, Sw-1200 | |
| Circuit Board | A-1059-609-A | Sony Mounted C. Board,ccm-53_ | |
| Circuit Board | A-1059-605-A | Sony Mounted C. Board,ma-130_ Compl | |
| Circuit Board | A-1159-020-A | Sony Mounted C.baord, Ky-566g | |
| Circuit Board | A-1159-024-A | Sony Mounted C.board, Ccm-53g | |
| Circuit Board | A-1159-023-A | Sony Mounted C.board, Ma-130g Compl | |
| Circuit Board | A-1159-021-C | Sony Mounted C.board, Mec-24g | |
| Circuit Board | A-1159-021-B | Sony Mounted C.board, Mec-24g | |
| Circuit Board | A-1059-622-A | Sony Mounted C.board, Se-746 | |
| Circuit Board | A-1059-652-A | Sony Mounted C.board, Se-753 | |
| Circuit Board | A-1059-654-A | Sony Mounted C.board, Se-754 | |
| Circuit Board | A-1059-614-A | Sony Mounted C.board, Su-84 | |
| Circuit Board | A-1059-616-A | Sony Mounted C.board, Su-85 | |
| Circuit Board | A-1059-618-A | Sony Mounted C.board, Su-86 | |
| Circuit Board | A-1059-620-A | Sony Mounted C.board, Su-87 | |
| Nut | 7-684-026-04 | Sony Nut M6 Type2 (Ep-fe/zn/cm2) | |
| 1-795-902-21 | Sony Oscillator, Crystal | ||
| A-1060-916-A | Sony Pad Assembly, Separetion | ||
| Pad | A-8279-999-E | Sony Pad Assembly,separetion | |
| Pad | A-8279-999-D | Sony Pad Assembly,separetion | |
| Pad | A-8279-999-C | Sony Pad Assembly,separetion | |
| Pad | A-8279-999-B | Sony Pad Assembly,separetion | |
| Pad | A-5013-442-B | Sony Pad Assy,separetion | Y |
| Panel | 3-854-576-03 | Sony Panel,front | |
| 3-854-576-02 | Sony Panel,front | ||
| 3-854-576-01 | Sony Panel,front | ||
| 8-719-052-69 | Sony Photo Interrupter Rpi-352 | ||
| 6-600-670-02 | Sony Photo Interrupter Rpi-352c1n | ||
| 6-600-670-01 | Sony Photo Interrupter Rpi-352c1n | ||
| Connector | 1-764-099-11 | Sony Pin, Connector (Pc Board) 14P | |
| Connector | 1-764-087-21 | Sony Pin, Connector (Pc Board) 14P | |
| Connector | 1-695-480-21 | Sony Pin, Connector (Pc Board) 2P | |
| Connector | 1-695-479-11 | Sony Pin, Connector (Pc Board) 2P | |
| Connector | 1-565-874-11 | Sony Pin, Connector (Pc Board) 2P | |
| Connector | 1-774-730-21 | Sony Pin, Connector (Pc Board) 3P | |
| Connector | 1-764-088-11 | Sony Pin, Connector (Pc Board) 3P | |
| Connector | 1-774-863-11 | Sony Pin, Connector (Pc Board) 8P | |
| Connector | 1-770-160-21 | Sony Pin, Connector (Smt) 2P | |
| Connector | 1-785-586-11 | Sony Pin, Connector 10P | |
| Connector | 1-818-628-11 | Sony Pin, Connector 14P | |
| Connector | 1-580-055-21 | Sony Pin, Connector 2P | |
| Connector | 1-695-320-11 | Sony Pin,connector (2P)(smd)(1.5mm) | |
| Connector | 1-691-550-11 | Sony Pin,connector (3P)(smd)(1.5mm) | |
| Connector | 1-573-290-21 | Sony Pin,connector (4P)(smd)(1.5mm) | |
| Connector | 1-565-396-11 | Sony Pin,connector 10P | |
| Connector | 1-580-056-21 | Sony Pin,connector 3P | |
| Connector | 1-750-005-11 | Sony Pin,connector 4P | |
| Connector | 1-565-875-11 | Sony Pin,connector(pc Board)3p | |
| Pin | 3-854-466-01 | Sony Pin,offset | |
| Pin | 3-703-358-06 | Sony Pin,parallel (2X14) (Steel) | |
| Shield | 3-869-768-01 | Sony Plate Dm,shield | |
| Plate | 3-854-587-01 | Sony Plate(power),light Guide | |
| Plate | 3-854-579-01 | Sony Plate(print),light Guide | |
| Plate | 3-854-446-01 | Sony Plate,inter Lock | |
| Plate | 3-854-435-01 | Sony Plate,platen Earth | |
| Plate | 3-854-568-02 | Sony Plate,protection | |
| Plate | 3-854-585-01 | Sony Plate,switch | |
| Plate | 3-854-428-01 | Sony Platen | |
| Connector | 1-564-524-11 | Sony Plug,connector (9P)(l-type) | |
| 3-854-419-02 | Sony Pulley,capstan | ||
| 3-854-419-01 | Sony Pulley,capstan | ||
| Belt, Pulley | 3-854-419-03 | Sony Pulley,capstan | |
| Belt, Pulley | 3-854-462-02 | Sony Pulley,idler | |
| 1-724-561-11 | Sony Pwb, Ma-430z Combined | ||
| Rail | 3-854-443-04 | Sony Rail(l),ribbon | |
| Rail | 3-854-443-03 | Sony Rail(l),ribbon | |
| 3-854-443-01 | Sony Rail(l),ribbon | ||
| 3-854-443-05 | Sony Rail(l),ribbon | Y | |
| 3-854-440-05 | Sony Rail(l),tray | ||
| Tray, Support , Ice Maker Tray | 3-854-440-04 | Sony Rail(l),tray | |
| 3-854-440-01 | Sony Rail(l),tray | ||
| Tray, Support , Ice Maker Tray | 3-854-440-02 | Sony Rail(l),tray | |
| Rail | 3-854-444-04 | Sony Rail(r),ribbon | |
| 3-854-444-01 | Sony Rail(r),ribbon | ||
| Rail | 3-854-444-05 | Sony Rail(r),ribbon | Y |
| 3-854-441-04 | Sony Rail(r),tray | ||
| 3-854-441-01 | Sony Rail(r),tray | ||
| Tray, Support , Ice Maker Tray | 3-854-441-03 | Sony Rail(r),tray | |
| Switch | 1-468-611-15 | Sony Regulator, Switching | |
| Switch | 1-468-611-14 | Sony Regulator, Switching | |
| Switch | 1-468-611-13 | Sony Regulator, Switching | |
| 1-220-883-81 | Sony Res, Chip 36 (1005) | ||
| 1-233-575-21 | Sony Res, Chip Network 22 | ||
| 1-233-575-11 | Sony Res, Chip Network 22 | ||
| 3-854-464-02 | Sony Retainer,fan | ||
| Wire | 3-854-468-01 | Sony Retainer,harness | |
| 3-854-450-01 | Sony Retainer,mode | ||
| Sensor, Thermistor, Thermostat | 3-854-469-02 | Sony Retainer,ribbon Sensor | |
| Ring | 7-624-108-04 | Sony Ring,retaining;e-type 4(Steel) | Y |
| Switch | 3-854-555-01 | Sony Rod,power Switch | |
| Roller | 3-854-448-01 | Sony Roller,paper Guide | |
| Roller | 3-854-442-01 | Sony Roller,pickup | |
| 3-854-499-01 | Sony Roller,pinch | ||
| Roller | 3-855-704-02 | Sony Roller,pinch | |
| Roller | 3-854-508-01 | Sony Roller,press | |
| Roller | 3-854-465-01 | Sony Roller,ribbon | |
| Roller | 3-854-456-01 | Sony Roller,tension | |
| Screw | 4-951-620-62 | Sony Screw (2.6) | |
| Screw | 3-080-203-42 | Sony Screw (M2), New Truster, P2 | |
| Screw | 3-855-700-01 | Sony Screw +B M2.5 Eg Grip | |
| Screw | 7-685-861-09 | Sony Screw +Bvtt 2.6X5(ep-fe/zn/cm2 | |
| Screw | 7-685-755-04 | Sony Screw +Bvtt 3X14 (S) | |
| Screw | 7-628-254-00 | Sony Screw +Ps 2.6X5 | |
| Screw | 7-682-649-09 | Sony Screw +Ps 3X10 | Y |
| Screw | 7-682-645-04 | Sony Screw +Ps 3X4 (St) | |
| Screw | 7-682-647-09 | Sony Screw +Ps 3X6(ep-fe/zn/cm2) | |
| Screw | 7-628-254-40 | Sony Screw +Psw 2.6X12(ep-fe/znbk/c | |
| Screw | 7-628-254-10 | Sony Screw +Psw 2.6X6(ep-fe/znbk/cm | |
| Screw | 7-621-759-65 | Sony Screw +Psw 2.6X8(ep-fe/zn/cm2) | |
| Screw | 7-682-947-09 | Sony Screw +Psw 3X6 | |
| Screw | 7-682-961-09 | Sony Screw +Psw 4X8 | |
| 7-621-773-86 | Sony Screw +Ptt 2.6X4 (S) | ||
| Screw | 4-644-493-11 | Sony Screw(m2.6x4), Lock Ace | |
| Lock | 3-080-203-41 | Sony Screw(m2x5),lock Ace,p2 | |
| Screw | 4-886-821-11 | Sony Screw, M3 Case Stopper | |
| 4-644-493-13 | Sony Screw, New Truster (M2.6) | ||
| Screw | 4-644-493-12 | Sony Screw, New Truster (M2.6) | |
| Screw | 7-685-133-19 | Sony Screw,+btp2.6x6(ep-fe/znbk/cm2 | |
| Screw | 7-685-873-09 | Sony Screw,+bvtt 3X10 | |
| 7-621-775-10 | Sony Screw,+ptt 2X4(ep-fe/znbk/cm2) | Y | |
| Screw | 3-854-556-01 | Sony Screw,cover | |
| Screw | 7-627-556-58 | Sony Screw,precision +P2.6x5 | Y |
| Shaft | 3-854-429-01 | Sony Shaft,connect | |
| Shaft | 3-854-430-01 | Sony Shaft,head Fulcrum | |
| Shaft | 3-990-822-01 | Sony Shaft,paper Flap | |
| 3-854-806-03 | Sony Shield Plate,ma | ||
| Shield | 3-854-806-02 | Sony Shield Plate,ma | |
| Shield | 3-854-806-01 | Sony Shield Plate,ma | |
| Spacer | 3-854-449-01 | Sony Spacer,capstan | |
| Spacer | 3-854-447-01 | Sony Spacer,platen | |
| Ring | 3-854-758-01 | Sony Spring(b) | |
| Ring | 3-854-584-01 | Sony Spring(ribbon) | |
| Ring | 3-854-509-01 | Sony Spring,compression | |
| Ring | 3-854-558-01 | Sony Spring,compression(rod) | |
| Ring | 3-863-308-01 | Sony Spring,extension | |
| Ring | 3-855-949-02 | Sony Spring,extension | |
| Ring | 3-855-703-01 | Sony Spring,extension | |
| Ring | 3-855-702-01 | Sony Spring,extension | |
| Ring | 3-854-532-01 | Sony Spring,extension | |
| Ring | 3-854-528-01 | Sony Spring,extension | |
| Ring | 3-854-518-01 | Sony Spring,extension | |
| 3-854-500-01 | Sony Spring,extension | ||
| Ring | 3-854-512-01 | Sony Spring,torsion,flap Eject | |
| 3-854-775-02 | Sony Static Eliminator | ||
| 3-854-563-02 | Sony Stay,bottom(l) | ||
| 3-854-565-01 | Sony Stay,bottom(r) | ||
| 3-854-515-03 | Sony Stay,center | ||
| 3-854-562-03 | Sony Stay,chassis | ||
| 3-854-420-02 | Sony Stay,front Coner | ||
| 3-854-413-04 | Sony Stay,rear Coner | ||
| 3-854-421-04 | Sony Stay,top | ||
| 3-854-566-03 | Sony Stay,top(r) | ||
| Ring | 7-624-105-04 | Sony Stop Ring 2.3, Type -E | Y |
| Ring | 7-624-106-04 | Sony Stop Ring, Type-e3(czn-n4) | Y |
| Stopper | 3-660-004-01 | Sony Stopper,rod | |
| X-3608-872-1 | Sony Sub Assembly,arm(l),pickup | ||
| X-3608-873-1 | Sony Sub Assembly,arm(r),pickup | ||
| Base | A-8286-019-B | Sony Sub Assembly,chassis Base | |
| X-3608-861-5 | Sony Sub Assembly,head Arm(l) | ||
| X-3608-862-5 | Sony Sub Assembly,head Arm(r) | ||
| X-3608-876-6 | Sony Sub Assembly,main Chassis | ||
| Lever | X-3608-857-4 | Sony Sub Assembly,mode Lever(l) | |
| Lever | X-3608-858-5 | Sony Sub Assembly,mode Lever(r) | |
| X-3608-867-1 | Sony Sub Assembly,pinch Arm(l) | ||
| X-3608-868-1 | Sony Sub Assembly,pinch Arm(r) | ||
| X-3608-871-2 | Sony Sub Assembly,stay,bottom | ||
| Motor,Ice Maker Motor | X-3608-860-2 | Sony Sub Assembly,stp Motor Bracket | |
| A-5007-490-A | Sony Sub Assembly,swing | ||
| X-3608-859-2 | Sony Sub Assembly,tension Arm | ||
| X-3608-875-1 | Sony Sub Assembly,tension Arm(s) | ||
| X-3608-870-2 | Sony Sub Assembly,tray,latch | ||
| X-3608-870-1 | Sony Sub Assembly,tray,latch | ||
| Motor,Ice Maker Motor | X-3608-865-1 | Sony Sub Assy,dc Motor(rf) | |
| Motor,Ice Maker Motor | X-3608-878-1 | Sony Sub Assy,dc Motor(rk) | |
| Lever | X-3608-874-1 | Sony Sub Assy,lever,lift Paper | |
| X-3608-877-2 | Sony Sub Assy,swing | ||
| Latch | X-3608-870-3 | Sony Sub Assy,tray,latch | |
| Wire | 1-963-026-11 | Sony Sub Harness | |
| Switch | 1-572-988-11 | Sony Switch, Micro | |
| Switch | 1-571-433-21 | Sony Switch, Push (Ac Power) | |
| Switch | 1-572-921-11 | Sony Switch,key Board | |
| Switch | 1-554-088-41 | Sony Switch,key Board | |
| Switch | 1-572-595-11 | Sony Switch,tactile (Reflow Type) | |
| 3-736-363-32 | Sony Tapping B2x4 | ||
| 3-736-363-31 | Sony Tapping B2x4 | ||
| Terminal | 3-175-740-01 | Sony Terminal | |
| 3-990-273-11 | Sony Terminal, P.e. | ||
| Terminal | 3-990-273-01 | Sony Terminal, P.e. | |
| Sensor, Thermistor, Thermostat | 1-803-383-11 | Sony Thermistor (103Kt1608-1p) | |
| Belt, Pulley | 3-854-460-01 | Sony Timing Belt(100tn10-5.0t) | |
| Belt, Pulley | 3-854-457-01 | Sony Timing Belt(220tn10-5.0t) | Y |
| 3-854-591-04 | Sony Top,cover | ||
| 3-854-591-03 | Sony Top,cover | ||
| 3-854-591-02 | Sony Top,cover | ||
| 3-854-591-01 | Sony Top,cover | ||
| Ring | 3-854-477-01 | Sony Torsion Spring | |
| Ring | 3-854-479-01 | Sony Torsion Spring | |
| 8-729-209-73 | Sony Transistor 2Sa1213y-te12l | ||
| Transistor | 8-729-026-53 | Sony Transistor 2Sa1576a-t106-qr | |
| Transistor | 8-729-051-23 | Sony Transistor 2Sa2018tl | |
| Transistor | 8-729-820-86 | Sony Transistor 2Sb1121-st | |
| Transistor | 8-729-053-92 | Sony Transistor 2Sb1424-t100-qr | |
| 8-729-901-80 | Sony Transistor 2Sc1623-l5l6 | ||
| U-0013-770-U | Sony Transistor 2Sc4081-r | ||
| 8-729-140-75 | Sony Transistor 2Sd999-clock | ||
| Transistor | 6-550-988-01 | Sony Transistor Cpt-184s-c-ts- | |
| Transistor | 6-550-794-01 | Sony Transistor Cpt-184s-c-tu-bcd | |
| Transistor | 8-729-928-37 | Sony Transistor Dta114ee | |
| Transistor | 8-729-928-91 | Sony Transistor Dtc114ee | |
| Transistor | 6-550-549-01 | Sony Transistor Dtc114euaft106 | |
| Transistor | 8-729-929-08 | Sony Transistor Dtc123je | |
| Transistor | 8-729-027-52 | Sony Transistor Dtc124eka-t146 | |
| Transistor | 8-729-928-82 | Sony Transistor Dtc144ee | |
| Transistor | 6-550-354-01 | Sony Transistor Rtq035p02 | |
| Transistor | 6-550-376-01 | Sony Transistor Umx1n-tn | |
| Tray, Support , Ice Maker Tray | A-8279-997-A | Sony Tray Assembly, Paper Prepare | |
| Tray, Support , Ice Maker Tray | A-8279-997-J | Sony Tray Assembly,paper Prepare | |
| Tray, Support , Ice Maker Tray | A-8279-997-G | Sony Tray Assembly,paper Prepare | |
| Tray, Support , Ice Maker Tray | A-8279-997-F | Sony Tray Assembly,paper Prepare | |
| A-8279-997-D | Sony Tray Assembly,paper Prepare | ||
| A-8279-997-C | Sony Tray Assembly,paper Prepare | ||
| Tray, Support , Ice Maker Tray | A-8279-997-H | Sony Tray Assembly,paper Prepare | |
| Tray, Support , Ice Maker Tray | A-8279-997-L | Sony Tray Assy, Paper Prepare | Y |
| A-8286-174-B | Sony Tray(s)assembly,paper Prepare | ||
| Tray, Support , Ice Maker Tray | A-8286-174-C | Sony Tray(s)assembly,paper Prepare | |
| 1-813-213-21 | Sony Vibrator, Ceramic | ||
| 1-795-094-11 | Sony Vibrator, Ceramic | ||
| 1-795-838-21 | Sony Vibrator, Ceramic | ||
| 1-813-369-11 | Sony Vibrator, Ceramic | ||
| 1-795-613-11 | Sony Vibrator, Crystal (27Mhz) | ||
| 7-623-425-07 | Sony Washer Lw 6 (Type B) | ||
| Washer | 3-696-510-01 | Sony Washer(3),stopper (Pla) | |
| Washer | 3-669-596-01 | Sony Washer,2.3 (Pla) | Y |
| 3-854-434-01 | Sony Worm(m) Wheel | ||
| Gear, Wheel | 3-854-434-02 | Sony Worm(m) Wheel | Y |
| Gear, Wheel | 3-854-475-01 | Sony Worm(r) Wheel |
