Manufacturer
Sony Replacement Parts

Model Number
SEL1670Z

Description
Vario-tessar T E 16-70Mm F/4 Za Oss Lens

Interactive Exploded View

Interactive Exploded View - view assemblies diagrams and click the part you need

CategoryPart NumberDescriptionDemandAvailability
HolderX-2587-168-1
Sony 1St Lens Holder Assy
Schematic Location: 52
YIn Stock In stock
113.95
Ring4-452-415-02
Sony 1St Lens Ring (9107)
Schematic Location: 2
Ships in 6 days
60.95
4-452-398-01
Sony 1St Moving Barrel (9107)
Schematic Location: 53
No
X-2587-169-1
Sony 2Nd Group Assy
Schematic Location: 102
YShips in 6 days
171.95
Shield4-477-490-01
Sony 2Nd Light Shield Sheet B (9107)
Schematic Location: 101
YIn Stock In stock
9.95
A-1938-678-A
Sony 3Rd Group Assy
Schematic Location: 104
No
A-1938-679-A
Sony 4Th Group Assy
Schematic Location: 105
YIn Stock In stock
124.95
J-6082-800-A
Sony Adjustment For Optical AxisShips in 6 days
100.95
Washer4-164-812-81
Sony Back WasherShips in 6 days
5.95
Washer4-164-812-71
Sony Back WasherShips in 6 days
5.95
X-2547-686-1
Sony Bl Contact_box Assy
Schematic Location: 62
In Stock In stock
10.95
4-452-506-01
Sony Cam Follower A(4.4)No
4-452-507-02
Sony Cam Follower B(4.4_4.0_3.5)Ships in 6 days
11.95
Base4-452-511-01
Sony Cam Follower Base A (9107)
Schematic Location: 72
Ships in 6 days
9.95
4-452-508-31
Sony Cam Follower C(4.4_4.0)Ships in 6 days
8.95
4-452-509-31
Sony Cam Follower D(4.4_4.0_3.5)Ships in 6 days
7.95
Pin4-452-531-01
Sony Cam Pin A (9107)
Schematic Location: 70
Ships in 6 days
5.95
Pin4-452-532-03
Sony Cam Pin B (9107)
Schematic Location: 107
Ships in 6 days
5.95
Pin4-452-533-03
Sony Cam Pin C (9107)
Schematic Location: 109
Ships in 6 days
5.95
Pin4-452-536-03
Sony Cam Pin E (9107)
Schematic Location: 111
Ships in 6 days
5.95
Circuit BoardA-2115-125-A
Sony Cl-1013 Board, Complete (Service)
Schematic Location: 54
In Stock In stock
68.95
Label2-886-553-01
Sony Decoration Plate (Cz)
Schematic Location: 58
Ships in 6 days
24.95
Gasket , Seal4-441-121-11
Sony Esd Gasket
Schematic Location: 6,56
YShips in 4 days
5.95
Lock4-452-410-01
Sony F Lock Pin (9107)
Schematic Location: 5
In Stock In stock
5.95
Screw4-452-402-11
Sony Filter Screw Barrel (9107)
Schematic Location: 4
YIn Stock In stock
13.95
Cover,CapX-2587-177-1
Sony Front Cover Assy
Schematic Location: 7
In Stock In stock
31.95
X-2582-535-2
Sony Front Lens Cap
Schematic Location: 901
YIn Stock In stock
31.95
Bush4-467-198-01
Sony Gom Bush B (9109)
Schematic Location: 76
No
Case4-471-161-02
Sony Lens Case
Schematic Location: 904
No
Hood4-452-476-02
Sony Lens Hood
Schematic Location: 903
In Stock In stock
55.95
1-888-281-11
Sony Lf-2048 Flexible Pwb (Cn9107)
Schematic Location: 69
YIn Stock In stock
19.95
4-468-083-21
Sony Manual, InstructionShips in 6 days
5.95
RingX-2587-176-1
Sony Mf Ring Assy
Schematic Location: 8
Ships in 6 days
30.95
4-723-645-01
Sony Mount
Schematic Location: 61
YShips in 6 days
62.95
4-468-083-01
Sony Operating Instructions
Schematic Location: 905
Ships in 6 days
5.95
A-1938-686-A
Sony Optical Block For ServiceNo
A-1938-682-A
Sony Outer Barrel Assy
Schematic Location: 68
YShips in 6 days
52.95
4-455-711-01
Sony Outer Barrel Sheet (9107)
Schematic Location: 12
Ships in 6 days
5.95
Belt, Pulley4-462-978-02
Sony Protection Belt 5 (9107)
Schematic Location: 9
Ships in 6 days
5.95
Cover,CapX-2587-178-2
Sony Rear Cover Assy
Schematic Location: 57
In Stock In stock
92.95
Lens4-159-701-03
Sony Rear Lens Cap
Schematic Location: 902
No
Shield4-452-422-01
Sony Rear Light Shield Barrel (9107)
Schematic Location: 64
In Stock In stock
5.95
Rubber4-452-456-01
Sony Rubber Bush A (9107)
Schematic Location: 75
YIn Stock In stock
5.95
Adhesive2-649-300-01
Sony Rubber Bush Sheet (9107) (Note 2)
Schematic Location: 74
Ships in 6 days
37.95
A-5014-923-A
Sony S-2nd Group Assy (Uc)No
A-5014-922-A
Sony S-3rd Group Assy (Uc)YIn Stock In stock
147.95
A-5014-921-A
Sony S-stationary Barrel Assy (Uc)No
Screw3-254-135-01
Sony Screw (B1.4)
Schematic Location: 77
Ships in 6 days
5.95
Screw4-299-469-01
Sony Screw M1.4 (Ch)
Schematic Location: 63
Ships in 6 days
5.95
Screw4-298-700-01
Sony Screw, Tapping B2 (Ch)
Schematic Location: 59
YIn Stock In stock
2.95
A-1938-676-A
Sony Stationary Barrel Assy
Schematic Location: 103
Ships in 6 days
111.95
Screw4-298-699-01
Sony Stopper Screw (Ch)
Schematic Location: 65
In Stock In stock
5.95
4-300-113-11
Sony Tapping (1.7) (Ch)
Schematic Location: 3,51
In Stock In stock
5.95
Ring4-452-465-01
Sony Z Lock Ring (9107)
Schematic Location: 10
YIn Stock In stock
5.95
A-1938-683-A
Sony Zm Pot Assy
Schematic Location: 67
YShips in 6 days
27.95
Cover,Cap4-452-417-02
Sony Zoom Cover (9107)
Schematic Location: 11
YShips in 6 days
40.95
4-452-535-02
Sony Zoom Linkage Pin (9107)
Schematic Location: 55
No
Ring4-452-407-01
Sony Zoom Ring (9107)
Schematic Location: 73
In Stock In stock
12.95
